Product Name: GP-type reinforced concrete pipe machine
Model No.: GP120-2
Usage: to produce reinforced concrete pipe
Unit: unit

Declarations

The GP-type reinforced concrete pipe machine is made from the principle of suspension roll forming which can produce concrete pipes from 600mm to 120mm diameter, and 2 meters long reinforced concrete pipe with certain molds. The machine is well designed, so that gives consumers a reliable performance, and a low fault machine. It is also easy to operate. It will produce a good amount of concrete pipes in a short period of time, in order to save consumer's time. There are several molds interfaces available to use on the machine, such as flat, I stand, jack and other commitments. The machines are sold worldwide such as Southeast Asia, Africa, and the Middle East. It is a well know and deeply trusted brand name.

Note: It can roll into concrete pipe from the inner diameter of 300mm of concrete to 600mm, 2000mm long concrete pipes. adding reinforcement cage will be reinforced concrete pipe. Two people can be sufficient for providing the materials, production process is simple, making one concrete can take up to 3-5 minutes. And the operators do not need to be trained for a long time. It is a simple, reliable, low cost machine. The machine is equipped with powerful 15kw motor. Every year a large number of equipment have been exported to Vietnam, Indonesia, Thailand Southeast Asia, Africa, Middle East and other countries and regions.

Concrete pipe machine: Sanlong is a professional manufacturer of concrete pipe machione in CHINA. We can provide you with good quality products and competitive prices

During the past 10 years, our Weili brand products have been exported to over many countries such as vietnam, africa, philippines, and so on and won high reputations. You can choose your preferred products freely among our various styles. On the other hand, we can make goods according to your requirements. So OEM is always welcome.

Concrete Pipe Machine:

Specification:     XG600         XG1200        XG1500

Pipe range:       300-600mm     800-1200mm    1000-1500mm

Pipe Length:      2000mm       2000mm        2000mm

Motor Power      15KW        30KW           55KW

Model of Motor:   YCT225-4B    YCT315-4A     YCT355-4A

Diameter of Roller: 140mm       173mm         325mm

Speed of Roller:   83-833 r/min   69-687 r/min    65-653 r/min

Advantage: Invironment protection, concrete materails consupion low, no serosity

Applacation: Highway curlvert, drian off water for municiple administration
